Images and brands are for information purposes only; available models and configurations may differ.
Rental Rates:
- 3 Hour $ 162.00
- Day $ 270.00
- Week $ 810.00
- 4 Week $ 2,430.00
Loader rental includes 1-bucket and trailer.
Rental includes up to 8 hours of meter use in a 24-hour time period. A $250.00 security deposit is required at reservation or check-out. Fuel additional.
Additional Attachments:
Product Description
The TX525 Mini Track Loader delivers big machine performance in a personal package. The TX525 combines the attachment versatility of its larger sibling Bobcat machines with the convenience of a walk-behind loader. Its small size and turf-friendly track drive make the TX525 a great solution to limited access and low-disturbance tasks. The innovative control panel makes the TX525 easy to operate, and the optional ride-on platform adds comfort and conveniences to this top performer.
Product Specifications (Specifications may change due to continuous product development)
| Air Filter |
Two-stage, heavy-duty, remote |
| Cooling System |
Liquid Cooled |
| Displacement (cc) |
901 |
| Displacement (cu. in.) |
55 |
| Dump Angle |
38 degrees |
| Dump Height (cm) |
117.1 |
| Dump Height (inches) |
46.1 |
| Engine Make |
Kubota |
| Engine Model |
D902E3B |
| Fuel Tank (gallons) |
6 |
| Fuel Tank (liters) |
23 |
| Fuel Type |
Diesel |
| Ground Clearance (cm) |
11.6 |
| Ground Clearance (inches) |
4.6 |
| Ground Pressure |
5.2 psi |
| Ground Speed Forward (mph) |
4.5 |
| Ground Speed Foward (km/h) |
7.2 |
| Ground Speed Reverse (km/h) |
3.2 |
| Ground Speed Reverse (mph) |
2 |
| Hinge Pin Height (cm) |
167.1 |
| Hinge Pin Height (inches) |
65.8 |
| Hydraulic Flow |
16.9 gpm (each pump) |
| Hydraulic Flow Auxiliary |
13.8 gpm |
| Loader Arms |
Radial |
| Manufacturer's Gross HP Rating (HP) |
24.8 |
| Manufacturer's Gross HP Rating (kW) |
18.5 |
| Max Operating Height (cm) |
228.8 |
| Max Operating Height (inches) |
90.1 |
| Oil Capacity (liters) |
3.63 |
| Oil Capacity (quarts) |
3.84 |
| Overall Height w/bucket (cm) |
117 |
| Overall Height w/bucket (inches) |
46.1 |
| Overall Height w/o bucket (cm) |
117 |
| Overall Height w/o bucket (inches) |
46.1 |
| Overall Length w/bucket (cm) |
233.6 |
| Overall Length w/bucket (inches) |
92 |
| Overall Length w/o bucket (cm) |
179.5 |
| Overall Length w/o bucket (inches) |
70.7 |
| Overall Width w/bucket (cm) |
86.5 |
| Overall Width w/bucket (inches) |
33.7 |
| Overall Width w/o bucket (cm) |
86.5 |
| Overall Width w/o bucket (inches) |
33.7 |
| Rated Operating Capacity* (kg) |
250 |
| Rated Operating Capacity* (lbs) |
553 |
| Reach – Fully Raised (cm) |
55.3 |
| Reach – Fully Raised (inches) |
21.8 |
| Reservoir Capacity (gallons) |
10 |
| Reservoir Capacity (liters) |
37.8 |
| RPM |
3400 |
| Track Length (inches) |
96.6 |
| Track Length(cm) |
245.3 |
| Track Width (cm) |
14.9 |
| Track Width (inches) |
5.9 |
| Tracks |
Sprocket-drive, 10 road wheels per side |
| Traction |
Dual Hydrostatic Pump |
| Weight (kg) |
863 |
| Weight (lbs) |
1904 |
| Wheelbase (inches) |
31.2 |
|
