Jumping Jack Compactor

Images and brands are for information purposes only; available models and configurations may differ.

Rental Rates

• 3 Hour              $     54.00
• Day                   $     90.00
• Week                 $   270.00
• 4 Week              $    810.00

Product Description

The MT-55F is an innovative 4-cycle Mikasa rammer that offers improvements from top to bottom.

It generates 2,250 pounds (1,000 kg) of impact force and weighs 126 pounds (57 kg). The rammer is ideal for backfill compaction of underground trenches for water, gas, sewer and utility lines. The MT-55F is perfect for low-noise applications and its octagonal shoe lowers vibration during use on small asphalt applications. The MT-55F features a steel plate on the shoe bottom that wraps around to protect the sides of the shoe.

Product Specifications (Specifications may change due to continuous product development)

Performance Data

•

• Blows/Minute: 695

• Impact Force: 2,250 (1,000)

• Travel Speed ft.(m)per min.: 46 (14)

• Maximum Area Capacity sq. ft. (sq. m) pm: 2,392 (222)

Power Source

• Engine Power - HP (kW): 2.6

• Fuel Tank Capacity - gal (liters): 2.1 (2)

• Engine Model: EH09

• Fuel Type: Gasoline

• Engine Make: Robin

Dimensions

• Shoe Size WxL: 10.4x13.4 (265x340)

• Overall Height - in. (cm): 40.6 (1,030)

• Overall Length - in. (cm): 26.8 (680)

• Overall Width - in. (cm): 13.8 (350)

• Operating Weight - lbs (kg): 126 (57)
