We Rent Most Everything!
  • Lift, Bucket (Aerial Towable)

    $156.00
    Enter Date Item Required: Availability must be confirmed by phone or email.

    Images and brands are for information purposes only; available models and configurations may differ.

    Product Description

    Genie’s trailer mounted booms are an excellent value in high-reach equipment. The TZ-50 provides industry leading outreach and working range and the highest tow speed rating available. The TZ-50 also provides many unique features, such as hydraulic outriggers and automatic machine leveling.

    Product Specifications (Specifications may change due to continuous product development)

    Model
    US
    Metric
    Working height*
    55 ft 6 in
    17.1 m
    Platform height
    49 ft 6 in
    15.1 m
    A
    Height – stowed
    6 ft 10 in
    2.08 m
    B
    Length – stowed
    23 ft 16 in
    7.16 m
    C
    Width – stowed
    5 ft 6 in
    1.68 m
    D
    Ground clearance
    10 in
    25 cm
    E
    Platform length
    27 in
    68.5 cm
    F
    Platform width
    44 in
    1.1 m
    G
    Platform railing height
    44 in
    1.1 m
    Entry height
    20 in
    51 cm
    Working outreach
    29 ft 2 in
    8.9 m
    Up and over clearance
    22 ft
    6.7 m
    Outrigger footprint – length
    14 ft 4 in
    4.37 m
    Outrigger footprint – width
    14 ft 4 in
    4.37 m
    Outrigger type
    hydraulic
    Leveling capability
    10°
    10°

    Lift capacity
    – ANSI, CSA
    – CE


    500 lb
    440 lb

    227 kg
    200 kg

    Turntable rotation

    359° non-continuous
    Tow speed rating
    60 mph
    97 km/h
    Drive speed
    .85 mph
    1.37 km/h
    Power sources
    DC: 24V (4 6V 225 AH batteries)
    Hybrid: 24V (4 6V 244 AH batteries)
    and Honda Gas 5.5 hp (4.1 kw)

    Tires
    – ANSI, CSA
    – CE


    ST225/75 R15
    215 R14C
    Gradeability
    20%
    20%
    Hydraulic tank capacity
    4.75 gal
    18 litre
    Fuel tank capacity
    .95 gal
    3.6 litre
    Tongue weight
    400 lb
    181 kg
    Machine weight
    – ANSI, CSA, CE

    4,400 lb

    1,996 kg


    *The metric equivalent of working height adds 2 m to platform height.
    U.S. adds 6 ft to platform height.
